MyInvois Middleware Gateway

Open-source middleware gateway for Malaysia’s MyInvois e-invoicing system. A production-ready REST API layer between your applications and the official LHDN MyInvois API, handling authentication, digital signing, document submission, status polling, and multi-tenant management.

Validated with Both v1.0 and v1.1

This middleware has been validated against the MyInvois Sandbox and Production APIs with all 9 document types in both v1.0 (unsigned) and v1.1 (digitally signed) formats:

Document Type	v1.0	v1.1 (Signed)
Invoice (01)	Validated	Validated
Credit Note (02)	Validated	Validated
Debit Note (03)	Validated	Validated
Refund Note (04)	Validated	Validated
Self-billed Invoice (11)	Validated	Validated
Self-billed Credit Note (12)	Validated	Validated
Self-billed Debit Note (13)	Validated	Validated
Self-billed Refund Note (14)	Validated	Validated
Consolidated Invoice	Validated	Validated

Disclaimer: This is an unofficial community project and is not affiliated with LHDN (Lembaga Hasil Dalam Negeri Malaysia). See DISCLAIMER.md for full terms.

Features
Quick Start
Architecture
API Reference
Digital Signing (v1.1)
Permissions & Roles
Configuration
Deployment
Postman Collection
Generated SDKs
Testing
Security
Troubleshooting
Contributing
License

Features

Feature	Description
4 Submission Types	Consolidated B2C, JustSave (draft), B2B (buyer TIN+BRN), B2C (buyer NRIC)
JWT Authentication	Access + Refresh tokens with role-based access control
Multi-Tenant Companies	Full company management with MyInvois credential storage
User Management	Users, Roles, Companies CRUD with permission gating
Document Operations	List, Status, PDF, Cancel, QR Code, Share Links
Digital Signing v1.1	X.509 PKCS#12 certificate signing per LHDN specification
Auto Status Polling	Background polling for submission status updates
Monthly Consolidation	Scheduled consolidation of draft B2C invoices
Draft Management	Save, edit, update, and submit draft invoices
Rate Limiting	Built-in LHDN rate limit enforcement (12/100/300 RPM)
ERP On-Behalf Mode	Single ERP credentials for multiple suppliers
POS Integration	Dedicated POS adapter with QR e-invoice registration
S3 Certificate Loading	Load P12 certificates from AWS S3 or local paths
Prometheus Metrics	Built-in `/metrics` endpoint for monitoring
Error Normalization	Consistent error envelope with correlationId tracking
4 Generated SDKs	TypeScript, Python, Java, C# clients from OpenAPI spec

Quick Start

Prerequisites

Node.js 22+
pnpm 9+
Docker (for local PostgreSQL and Redis)

1. Clone & Install

git clone https://github.com/zahidaramai/MyInvoice-SDK-Middleware.git
cd MyInvoice-SDK-Middleware
pnpm install

2. Start Infrastructure

docker compose -f docker/docker-compose.yml up -d

3. Configure Environment

cp .env.example .env
# Edit .env with your MyInvois credentials and database settings

4. Run Migrations & Seed

pnpm --filter @myinvois/storage prisma migrate dev
pnpm --filter @myinvois/storage prisma db seed

5. Start Gateway

pnpm --filter @myinvois/gateway dev

Gateway available at http://localhost:3000

curl -X POST http://localhost:3000/api/v1/auth/login \
  -H "Content-Type: application/json" \
  -d '{"email":"admin@example.com","password":"admin123"}'

Architecture

┌─────────────────┐     ┌──────────────────────────┐     ┌─────────────────┐
│                 │     │    MyInvois Gateway       │     │                 │
│  Your Dashboard │────>│  ┌──────────────────┐    │────>│  MyInvois API   │
│  (React/Vue)    │     │  │ JWT Auth         │    │     │  (LHDN)         │
│                 │     │  │ RBAC             │    │     │                 │
└─────────────────┘     │  │ Rate Limiting    │    │     └─────────────────┘
                        │  │ Digital Signing  │    │
┌─────────────────┐     │  │ JSON -> UBL 2.1  │    │
│  POS System     │────>│  │ Error Normalizer │    │
│                 │     │  └──────────────────┘    │
└─────────────────┘     └────────────┬─────────────┘
                                     │
                        ┌────────────▼─────────────┐
                        │  Background Workers       │
                        │  - Auto Status Poller     │
                        │  - Monthly Consolidation  │
                        └────────────┬─────────────┘
                                     │
          ┌──────────────────────────┼──────────────────────────┐
          │                          │                          │
   ┌──────▼──────┐           ┌───────▼───────┐          ┌──────▼──────┐
   │  PostgreSQL │           │    Redis      │          │  Prometheus │
   │  (Prisma)   │           │  (BullMQ +    │          │  (Metrics)  │
   │  10 models  │           │   Rate Limit) │          │             │
   └─────────────┘           └───────────────┘          └─────────────┘

API Reference

Base URL

http://localhost:3000/api/v1

All endpoints below are relative to the base URL. All endpoints except /auth/login require a JWT bearer token:

Authorization: Bearer <access_token>

Authentication Endpoints

Method	Endpoint	Description
POST	`/auth/login`	Login with email/password
POST	`/auth/logout`	Invalidate tokens
POST	`/auth/refresh`	Exchange refresh token for new access token
GET	`/auth/me`	Get current authenticated user
POST	`/auth/switch-company`	Switch active company context

{
  "accessToken": "eyJhbGciOiJIUzI1NiIs...",
  "refreshToken": "eyJhbGciOiJIUzI1NiIs...",
  "expiresIn": 900,
  "user": {
    "id": "abc123",
    "email": "admin@example.com",
    "name": "Admin",
    "role": "Admin"
  }
}

Submission Endpoints

Method	Endpoint	Description
POST	`/klcubelhdn/submit-consolidate`	Consolidated B2C invoice (daily sales)
POST	`/klcubelhdn/submit-justsave`	Save invoice as draft (no LHDN submission)
POST	`/klcubelhdn/submit-buyer`	B2B invoice (with buyer TIN + BRN)
POST	`/klcubelhdn/submit-personal`	B2C invoice (with buyer NRIC)

Legacy Unified Endpoint

Method	Endpoint	Description
POST	`/documents/submit`	Unified submission with flags

Submission Request Format

POST /api/v1/klcubelhdn/submit-buyer
{
  "companyId": "uuid-of-company",
  "documentVersion": "1.1",
  "invoices": [{
    "invoiceNumber": "INV-2026-001",
    "invoiceDate": "2026-01-21T10:00:00Z",
    "amount": 100.00,
    "discount": 0,
    "rounding": 0,
    "taxAmount": 8.00,
    "total": 108.00,
    "buyer": {
      "tin": "C25235029040",
      "name": "Buyer Company Sdn Bhd",
      "idType": "BRN",
      "idValue": "20170104319",
      "address": "123 Main Street",
      "city": "Kuala Lumpur",
      "state": "14",
      "postalCode": "50000",
      "phone": "0123456789",
      "email": "buyer@example.com"
    },
    "items": [{
      "description": "Professional Services",
      "quantity": 1,
      "unitPrice": 100.00,
      "discount": 0,
      "taxCode": "01",
      "taxRate": 8,
      "taxAmount": 8.00,
      "total": 108.00
    }]
  }]
}

Document Endpoints

Method	Endpoint	Description
GET	`/documents`	List documents (with filters, pagination)
GET	`/documents/:uuid/status`	Get document status from MyInvois
GET	`/documents/:uuid/pdf`	Download PDF
POST	`/documents/:uuid/cancel`	Cancel submitted document
GET	`/documents/:uuid/qr`	Generate QR code (PNG)
GET	`/documents/:uuid/links`	Get all shareable links
POST	`/documents/:trackingId/submit`	Submit a saved draft
PUT	`/documents/:trackingId`	Update draft invoice data
DELETE	`/documents/:trackingId`	Delete draft invoice
GET	`/klcubelhdn/invoices/:trackingId`	Get full invoice details

List Documents

GET /api/v1/documents?companyId=xxx&status=VALID&page=1&limit=20

Document Status Values

Status	Description
`DRAFT`	Saved locally, not submitted
`PENDING`	Queued for submission
`SUBMITTED`	Sent to MyInvois, awaiting validation
`VALID`	Accepted by LHDN
`INVALID`	Rejected by LHDN
`CANCELLED`	Cancelled after validation

Management Endpoints

Users

Method	Endpoint	Description
GET	`/users`	List all users (paginated)
POST	`/users`	Create user
GET	`/users/:id`	Get user by ID
PUT	`/users/:id`	Update user
DELETE	`/users/:id`	Delete user
PUT	`/users/:id/role`	Assign role to user
POST	`/users/:userId/companies/:companyId`	Link user to company
DELETE	`/users/:userId/companies/:companyId`	Unlink user from company

Roles

Method	Endpoint	Description
GET	`/roles`	List all roles (paginated)
GET	`/roles/all`	Get all roles (for dropdowns)
GET	`/roles/permissions`	Get available permissions
POST	`/roles`	Create role
GET	`/roles/:id`	Get role by ID
PUT	`/roles/:id`	Update role
DELETE	`/roles/:id`	Delete role

Companies

Method	Endpoint	Description
GET	`/companies`	List companies (paginated)
GET	`/companies/all`	Get all companies (for dropdowns)
POST	`/companies`	Create company
GET	`/companies/:id`	Get company details
PUT	`/companies/:id`	Update company
DELETE	`/companies/:id`	Delete company
PUT	`/companies/:id/credentials`	Set MyInvois API credentials

POS Integration

Method	Endpoint	Description
POST	`/pos/register`	Register invoice for public QR sharing
POST	`/pos/invoices`	Bulk POS invoice upload
GET	`/pos/transactions`	Fetch POS transactions

Public Routes (No Auth)

Method	Endpoint	Description
GET	`/public/:posInvoiceId`	Public e-invoice registration page

Health & Monitoring

Method	Endpoint	Description
GET	`/health`	Basic health check
GET	`/healthz`	Kubernetes liveness probe
GET	`/readyz`	Readiness probe (DB + Redis)
GET	`/metrics`	Prometheus metrics
GET	`/version`	Version info

Digital Signing (v1.1)

Documents submitted with documentVersion: "1.1" are automatically signed using X.509 certificates per LHDN specification.

Certificate Setup

Option 1: Local PKCS#12 File

SIGNING_ENABLED=true
SIGNING_DEFAULT_VERSION=1.1
SIGNING_PKCS12_PATH=/path/to/certificate.p12
SIGNING_PKCS12_PASSPHRASE=your-password

Option 2: AWS S3

SIGNING_PKCS12_PATH=s3://your-bucket/certificates/signing.p12
SIGNING_PKCS12_PASSPHRASE=your-password

Option 3: PEM Files

SIGNING_CERT_PATH=/path/to/cert.pem
SIGNING_KEY_PATH=/path/to/key.pem
SIGNING_KEY_PASSPHRASE=your-password

Signing Process

Gateway receives document with documentVersion: "1.1"
Calculates document hash (SHA-256)
Signs hash with RSA-SHA256 using private key
Injects UBL XAdES signature into document
Submits signed document to MyInvois

Permissions & Roles

Role-based access control with 6 permissions:

Permission	Description	Endpoints
`submit:invoice`	Submit invoices to LHDN	`/klcubelhdn/*`, `/documents/submit`
`read:documents`	View documents and statuses	`/documents`, `/documents/:uuid/*`
`cancel:documents`	Cancel submitted documents	`/documents/:uuid/cancel`
`manage:users`	User CRUD operations	`/users/*`
`manage:roles`	Role CRUD operations	`/roles/*`
`manage:companies`	Company CRUD operations	`/companies/*`

Default Roles (Pre-seeded)

Role	Permissions
Admin	All 6 permissions
Invoice Manager	`submit:invoice`, `read:documents`, `cancel:documents`
Viewer	`read:documents`

Custom roles can be created via the API using any combination of the 6 permissions.

Configuration

Required Environment Variables

Variable	Description
`DATABASE_URL`	PostgreSQL connection string
`REDIS_URL`	Redis connection string
`JWT_SECRET`	Access token signing key (64 hex chars)
`JWT_REFRESH_SECRET`	Refresh token signing key (64 hex chars)

Optional Environment Variables

Variable	Default	Description
`PORT`	3000	Server port
`NODE_ENV`	development	Environment mode
`LOG_LEVEL`	debug	Logging level (debug/info/warn/error)
`JWT_ACCESS_EXPIRY`	15m	Access token TTL
`JWT_REFRESH_EXPIRY`	7d	Refresh token TTL
`MYINVOIS_ENV`	SANDBOX	MyInvois environment (SANDBOX/PROD)
`SIGNING_ENABLED`	false	Enable v1.1 document signing
`SIGNING_DEFAULT_VERSION`	1.0	Default document version
`SIGNING_PKCS12_PATH`	-	Path to P12 certificate
`SIGNING_PKCS12_PASSPHRASE`	-	P12 passphrase
`ERP_MODE`	false	Enable ERP intermediary mode
`ENABLE_MONTHLY_CONSOLIDATION`	false	Enable monthly draft consolidation
`METRICS_ENABLED`	true	Enable Prometheus metrics

Generate Secure Secrets

openssl rand -hex 32

Deployment

Option 1: Docker Compose

cp .env.production.template .env
# Edit .env with production values

docker compose -f docker/docker-compose.prod.yml up -d
docker compose exec gateway npx prisma migrate deploy

Option 2: AWS Elastic Beanstalk

Full guide: documentation/AWS-EB-DEPLOYMENT-GUIDE.md

./scripts/deploy-eb.sh v1.0.0

Option 3: Docker (Standalone)

docker build -t myinvois-gateway .
docker run -p 3000:3000 --env-file .env myinvois-gateway

Postman Collection

A comprehensive Postman collection is included with pre-built requests for all API endpoints.

Import

documentation/KLCubeLHDN-API-v1.1.2.postman_collection.json

Open Postman > Import > Upload the collection file
Set baseUrl variable to your API URL
Run “Login” first to get tokens
All subsequent requests use the token automatically

Generated SDKs

Auto-generated client SDKs from the OpenAPI specification:

Language	Location
TypeScript	`sdks/typescript/`
Python	`sdks/python/`
Java	`sdks/java/`
C# / .NET	`sdks/dotnet/`

OpenAPI spec: documentation/openapi.yaml

Testing

# Run all tests
pnpm test

# Run with coverage
pnpm test -- --coverage

# Run linting + type check + tests + build
pnpm check

# Run specific test file
pnpm --filter @myinvois/gateway test -- signing.test.ts

Test Structure

Type	Location
Unit tests	`packages/*/test/`
Route tests	`apps/gateway/src/routes/*/.test.ts`
Integration tests	`test/integration/`
E2E tests	`test/e2e/`
Negative tests	`apps/gateway/test/negative/`
Contract tests	`test/openapi/`

Project Structure

MyInvoice-SDK-Middleware/
├── apps/
│   ├── gateway/                 # REST API (Fastify)
│   │   ├── src/
│   │   │   ├── adapters/        # KLCubeLHDN + POS adapters
│   │   │   ├── auth/            # JWT authentication
│   │   │   ├── management/      # User/Role/Company CRUD
│   │   │   ├── polling/         # Auto status poller + consolidation
│   │   │   ├── public/          # Public QR registration
│   │   │   ├── config/          # Signing, S3 loader
│   │   │   ├── plugins/         # Fastify plugins
│   │   │   └── routes/          # Core v1 routes
│   │   ├── prisma/              # Database schema + migrations
│   │   └── test/                # Gateway tests
│   └── worker/                  # Background job processor (BullMQ)
├── packages/
│   ├── contracts/               # Shared TypeScript types
│   ├── core/                    # Rate limiter, error normalization
│   ├── myinvois-client/         # Typed MyInvois API client
│   ├── signing/                 # X.509 signing (v1.1)
│   └── storage/                 # Prisma ORM + PostgreSQL
├── sdks/                        # Generated client SDKs
│   ├── typescript/
│   ├── python/
│   ├── java/
│   └── dotnet/
├── docker/                      # Docker Compose configs
├── documentation/               # OpenAPI spec, deployment guides
├── scripts/                     # Build + deploy scripts
├── test/                        # E2E + integration tests
└── Dockerfile                   # Multi-stage production build

Database Models

Model	Purpose
`User`	Platform user accounts
`Role`	Roles with permission arrays
`Company`	Multi-tenant company entities with MyInvois credentials
`UserCompany`	User-Company many-to-many linking
`RefreshToken`	JWT refresh token tracking
`Invoice`	Invoice storage with full lifecycle
`Submission`	Gateway submission tracking
`SubmissionDocument`	Individual documents within submissions
`IdempotencyWindow`	10-minute deduplication window
`TinValidateCache`	TIN validation result caching

Tax Codes

Code	Description
01	Sales Tax (SST)
02	Service Tax
03	Tourism Tax
04	High-Value Goods Tax
05	Sales Tax on Low Value Goods
06	Not Applicable
E	Tax Exemption

State Codes

Code	State
01	Johor
02	Kedah
03	Kelantan
04	Melaka
05	Negeri Sembilan
06	Pahang
07	Pulau Pinang
08	Perak
09	Perlis
10	Selangor
11	Terengganu
12	Sabah
13	Sarawak
14	Kuala Lumpur
15	Labuan
16	Putrajaya
17	Not Applicable

Security

Best Practices

Use strong JWT secrets (64+ hex characters)
Enable HTTPS in production (via reverse proxy or load balancer)
Restrict database access to minimum required
Enable database encryption at rest
Rotate secrets regularly
Monitor application logs for anomalies

CORS

Currently allows all origins. To restrict, modify apps/gateway/src/app.ts:

cors({
  origin: ["https://your-domain.com"],
  methods: ["GET", "POST", "PUT", "DELETE", "OPTIONS"],
  allowedHeaders: ["Content-Type", "Authorization"],
  credentials: true,
})

Troubleshooting

Common Issues

Issue	Solution
401 Unauthorized	Token expired - use `/auth/refresh` for new token
403 Forbidden	Missing permissions or user not linked to company
429 Too Many Requests	Rate limit hit - respect `Retry-After` header
Certificate Errors	Verify `SIGNING_PKCS12_PATH` and passphrase
Database Connection	Check `DATABASE_URL` and PostgreSQL is running

Debug Commands

# Local dev with verbose logging
LOG_LEVEL=debug pnpm --filter @myinvois/gateway dev

# Test health
curl http://localhost:3000/health

# Docker logs
docker compose logs -f gateway

Commands Reference

# Development
pnpm install                              # Install all dependencies
pnpm --filter @myinvois/gateway dev       # Start gateway (hot reload)
pnpm build                                # Build all packages
pnpm check                                # Lint + typecheck + test + build

# Testing
pnpm test                                 # Run all tests
pnpm test -- --coverage                   # With coverage

# Database
pnpm --filter @myinvois/storage prisma migrate dev    # Run migrations
pnpm --filter @myinvois/storage prisma generate       # Generate client
pnpm --filter @myinvois/storage prisma db seed        # Seed database
pnpm --filter @myinvois/storage prisma studio         # Open Prisma Studio

# OpenAPI
npx @stoplight/spectral-cli lint documentation/openapi.yaml

Resources

External References

Project Documentation

Contributing

See CONTRIBUTING.md for guidelines.

Fork the repository
Create your feature branch (git checkout -b feature/my-feature)
Ensure tests pass (pnpm check)
Commit your changes
Push to the branch
Open a Pull Request

Developer

Zahid Aramai - Full-Stack Developer & System Architect


Website	zahidaramai.com
Email	hello@zahidaramai.com
GitHub	@zahidaramai

License

MIT License - see LICENSE file for details.

Built by Zahid Aramai

This site is open source. Improve this page.
